What is the Turbulator?
2024-11-20Leave a message
The turbulator, usually composed of a series of twisted metal sheets or wires, is installed inside the tubes of heat exchanger and is a device used to increase the heat exchange area and improve the heat exchange efficiency.
When two fluids with different temperatures flow in the tubes, the turbulator will change the flow state of the fluid, turning the originally relatively stable laminar flow into a complex turbulent flow, effectively transferring heat from the fluid to the heat exchange tube wall. At the same time, turbulence increases the mixing and disturbance inside the fluid, making the heat transfer more uniform and efficient.
The Turbulator Advantages:
⚑ Reduce the total thermal resistance of the heat exchanger during heat transfer, greatly improving the heat transfer coefficient of the heat exchanger
⚑ Can effectively inhibit the formation of dirt
⚑ Increase the heat transfer area in the heat exchange tube and enhance the heat transfer efficiency
⚑ Small size, easy to install, does not take up space
The Turbulator Shortcoming:
⚑ May increase the resistance of tube side
Turbulator Classify
The design of turbulators varies from simple geometric shapes to more complex structures to further enhance the complexity of fluid flow. These designs not only optimize the heat exchange process, but also reduce the deposition of dirt on the heat exchanger surface, extending the service life of the equipment.
⚑ Wire matrix turbulator
⚑ Rigid center rod wire turbulator
⚑ Finned hollow rod type turbulator
⚑ Spring turbulator
⚑ Twisted tape turbulator
The first three are made from metal wire, while the last one is made from metal sheet.
We supply twisted tape turbulators in a wide range of specifications and can customize them to meet customer requirements.
Material: Stainless steel 304, 316, 210, 410, etc.
Surface: Smooth cut, bright and burr-free
Size: - Width: 20-63.5mm
- Thickness: 0.5-5mm
Length: 1-6m
The Turbulator Applicable Industries
- Machinery manufacturing
- Chemical industry
- Shipbuilding industry
The Turbulator Applicable Equipment
- Boiler
- Tube heat exchanger
Twisted Tape Turbulator
